| LOW LOSS PE FOAM COAXIAL CABLE |
LLC-MFT100A
| Description |
| This document is the physical structure & Mechanical, Electrical Characteristics of LLC-MFT100A Cable based on 50 Ω Low Loss Foam Coaxial Cable. |
Replacement for |
|
| Physical Structure |
Inner Conductor |
Copper Clad Steel |
0.0177 in |
(0.45 mm ) |
Dielectric |
Solid Polyethylene
|
0.060 in
|
(1.52 mm ) |
1st Outer Conductor
|
Unsealed APA Tape
|
0.065 in
|
(1.65 mm )
|
2nd Outer Conductor
|
38AWG, 90% Tinned Copper Braid
|
0.081 in
|
(2.06 mm )
|
Jacket
|
Black PVC
|
0.110 in
|
(2.79 mm)
|
| Mechanical |
Product Weight |
9.4 lb/kft |
(14 kg/km) |
Minimum Bend Radius |
1.10 in |
(27.9 mm) |
| Electrical Characteristics |
Operation Frequency |
50 ~ 2500 ㎒ |
Characteristic Impedance |
50 ± 5 Ω |
Velocity of Propagation, Nom.
|
66 % |
Capacitance, Nom.
|
31.1 ㎋/kft
|
(102.0 ㎋/㎞)
|
Inner Conductor Resistance @ 20℃
|
81.7 Ω/kft |
(268 Ω/km) |
Outer Conductor Resistance @ 20℃
|
8.8 Ω/kft |
(29 Ω/km) |
LLC-MFT195
| Description |
| This document is the physical structure & Mechanical, Electrical Characteristics of LLC-MFT195 Cable based on 50 Ω Low Loss Foam Coaxial Cable.
|
Replacement for |
|
| Physical Structure |
Inner Conductor |
Solid Bare Copper
|
0.0370 in
|
(0.94 mm)
|
Dielectric |
Foamed Polyethylene
|
0.110 in
|
(2.79 mm)
|
1st Outer Conductor |
Sealed APA Tape
|
0.116 in
|
(2.95 mm)
|
2nd Outer Conductor |
36AWG, 95% Tinned Copper Braid
|
0.138 in
|
(3.51 mm)
|
Jacket |
Black PE
|
0.195 in
|
(4.95 mm)
|
| Mechanical |
Product Weight |
23.5 lb/kft
|
(35 kg/km)
|
Minimum Bend Radius |
1.95 in
|
(49.5 mm)
|
| Electrical Characteristics |
Operation Frequency |
30 ~ 6000 ㎒
|
Characteristic Impedance |
50 ± 3 Ω
|
Velocity of Propagation, Nom. |
80 % |
Capacitance, Nom. |
25.4 ㎋/kft
|
(83.3 ㎋/㎞)
|
Inner Conductor Resistance @ 20℃ |
7.6 Ω/kft
|
(25 Ω/km)
|
Outer Conductor Resistance @ 20℃ |
4.9 Ω/kft
|
(16 Ω/km)
|
LLC-MFT200
| Description |
| This document is the physical structure & Mechanical, Electrical Characteristics of LLC-MFT200 Cable based on 50 Ω Low Loss Foam Coaxial Cable. |
Replacement for |
|
| Physical Structure |
Inner Conductor |
Solid Bare Copper |
0.0441 in
|
(1.12 mm)
|
Dielectric |
Foamed Polyethylene |
0.116 in
|
(2.95 mm)
|
1st Outer Conductor |
Sealed APA Tape |
0.123 in
|
(3.12 mm)
|
2nd Outer Conductor |
36AWG, 95% Tinned Copper Braid |
0.144 in
|
(3.66 mm)
|
Jacket |
Black PE |
0.195 in |
(4.95 mm) |
| Mechanical |
Product Weight |
22.8 lb/kft |
(34 kg/km) |
Minimum Bend Radius |
1.95 in |
(49.5 mm |
| Electrical Characteristics |
Operation Frequency |
30 ~ 6000 ㎒ |
Characteristic Impedance |
50 ± 3 Ω |
Velocity of Propagation, Nom. |
82 % |
Capacitance, Nom. |
24.5 ㎋/kft
|
(80.3 ㎋/㎞)
|
Inner Conductor Resistance @ 20℃ |
5.5 Ω/kft |
(18 Ω/km) |
Outer Conductor Resistance @ 20℃ |
4.9 Ω/kft |
(16 Ω/km) |
LLC-MFT240
| Description |
| This document is the physical structure & Mechanical, Electrical Characteristics of LLC-MFT240 Cable based on 50 Ω Low Loss Foam Coaxial Cable. |
Replacement for |
|
| Physical Structure |
Inner Conductor |
Solid Bare Copper |
0.0559 in |
(1.42 mm) |
Dielectric |
Foamed Polyethylene |
0.150 in |
(3.81 mm) |
1st Outer Conductor |
Sealed APA Tape |
0.157 in |
(3.99 mm) |
2nd Outer Conductor |
36AWG, 95% Tinned Copper Braid |
0.178 in |
(4.52 mm)
|
Jacket |
Black PE |
0.240 in |
(6.10 mm) |
| Mechanical |
Product Weight |
34.3 lb/kft |
(51 kg/km) |
Minimum Bend Radius |
2.40 in |
(61.0 mm) |
| Electrical Characteristics |
Operation Frequency |
30 ~ 6000 ㎒ |
Characteristic Impedance |
50 ± 3 Ω |
Velocity of Propagation, Nom. |
83 % |
Capacitance, Nom. |
24.2 ㎋/kft
|
(79.4 ㎋/㎞)
|
Inner Conductor Resistance @ 20℃ |
3.4 Ω/kft |
(11 Ω/km) |
Outer Conductor Resistance @ 20℃ |
4.0 Ω/kft |
(13 Ω/km) |
LLC-MFT300
| Description |
| This document is the physical structure & Mechanical, Electrical Characteristics of LLC-MFT300 Cable based on 50 Ω Low Loss Foam Coaxial Cable. |
Replacement for |
|
| Physical Structure |
Inner Conductor |
Solid Bare Copper |
0.0701 in |
(1.78 mm) |
Dielectric |
Foamed Polyethylene |
0.190 in |
(4.83 mm) |
1st Outer Conductor |
Sealed APA Tape |
0.196 in |
(4.98 mm) |
2nd Outer Conductor |
36AWG, 95% Tinned Copper Braid |
0.225 in |
(5.72 mm) |
Jacket |
Black PE |
0.300 in |
(7.62 mm) |
| Mechanical |
Product Weight |
51.7 lb/kft |
(77 kg/km) |
Minimum Bend Radius |
3.00 in |
(76.2 mm) |
| Electrical Characteristics |
Operation Frequency |
30 ~ 6000 ㎒ |
Characteristic Impedance |
50 ± 3 Ω |
Velocity of Propagation, Nom. |
85 % |
Capacitance, Nom. |
23.9 ㎋/kft
|
(78.4 ㎋/㎞)
|
Inner Conductor Resistance @ 20℃ |
2.1 Ω/kft |
(7.0 Ω/km) |
Outer Conductor Resistance @ 20℃ |
2.2 Ω/kft |
(7.3 Ω/km) |
LLC-MFT400
| Description |
| This document is the physical structure & Mechanical, Electrical Characteristics of LLC-MFT400 Cable based on 50 Ω Low Loss Foam Coaxial Cable. |
Replacement for |
|
| Physical Structure |
Inner Conductor |
Solid Copper Clad Aluminum Wire
|
0.1091 in
|
(2.77 mm)
|
Dielectric |
Foamed Polyethylene |
0.285 in
|
(7.24 mm)
|
1st Outer Conductor |
Sealed APA Tape |
0.292 in
|
(7.42 mm)
|
2nd Outer Conductor |
34AWG, 95% Tinned Copper Braid
|
0.320 in
|
(8.13 mm)
|
Jacket |
Black PE |
0.405 in
|
(10.29 mm)
|
| Mechanical |
Product Weight |
71.2 lb/kft |
(106 kg/km) |
Minimum Bend Radius |
1.42 in |
(36.0 mm) |
| Electrical Characteristics |
Operation Frequency |
30 ~ 6000 ㎒ |
Characteristic Impedance |
50 ± 3 Ω |
Velocity of Propagation, Nom. |
85 % |
Capacitance, Nom. |
23.9 ㎋/kft
|
(78.4 ㎋/㎞)
|
Inner Conductor Resistance @ 20℃ |
1.5 Ω/kft |
(57.0 Ω/km) |
Outer Conductor Resistance @ 20℃ |
1.5 Ω/kft |
(5.0 Ω/km) |
LLC-MFT500
| Description |
| This document is the physical structure & Mechanical, Electrical Characteristics of LLC-MFT500 Cable based on 50 Ω Low Loss Foam Coaxial Cable. |
Replacement for |
|
| Physical Structure |
Inner Conductor |
Solid Copper Clad Aluminum Wire
|
0.1425 in |
(3.62 mm) |
Dielectric |
Foamed Polyethylene |
0.370 in |
(9.40 mm) |
1st Outer Conductor |
Sealed APA Tape |
0.376 in |
(9.55 mm) |
2nd Outer Conductor |
34AWG, 95% Tinned Copper Braid
|
0.407 in |
(10.34 mm)
|
Jacket |
Black PE |
0.500 in |
(12.70 mm) |
| Mechanical |
Product Weight |
106.2 lb/kft
|
(158 kg/km)
|
Minimum Bend Radius |
5.00 in
|
(127.0 mm)
|
| Electrical Characteristics |
Operation Frequency |
30 ~ 6000 ㎒ |
Characteristic Impedance |
50 ± 3 Ω |
Velocity of Propagation, Nom. |
86 % |
Capacitance, Nom. |
23.6 ㎋/kft
|
(77.5 ㎋/㎞)
|
Inner Conductor Resistance @ 20℃ |
0.82 Ω/kft |
(2.7 Ω/km) |
Outer Conductor Resistance @ 20℃ |
1.28 Ω/kft |
(4.20 Ω/km) |
LLC-MFT600
| Description |
| This document is the physical structure & Mechanical, Electrical Characteristics of LLC-MFT600 Cable based on 50 Ω Low Loss Foam Coaxial Cable. |
Replacement for |
|
| Physical Structure |
Inner Conductor |
Solid Coper Clad Aluminum Wire
|
0.1760 in |
(4.47 mm) |
Dielectric |
Foamed Polyethylene |
0.455 in |
(11.56 mm) |
1st Outer Conductor |
Sealed APA Tape |
0.463 in |
(11.76 mm) |
2nd Outer Conductor |
34AWG, 95% Tinned Copper Braid
|
0.491 in |
(12.47 mm) |
Jacket |
Black PE |
0.590 in |
(14.99 mm) |
| Mechanical |
Product Weight |
139.8 lb/kft
|
(208 kg/km)
|
Minimum Bend Radius |
5.90 in
|
(149.9 mm)
|
| Electrical Characteristics |
Operation Frequency |
30 ~ 6000 ㎒ |
Characteristic Impedance |
50 ± 3 Ω |
Velocity of Propagation, Nom. |
86 % |
Capacitance, Nom. |
23.3 ㎋/kft
|
(76.6 ㎋/㎞)
|
Inner Conductor Resistance @ 20℃ |
0.6 Ω/kft |
(2 Ω/km) |
Outer Conductor Resistance @ 20℃ |
1.2 Ω/kft |
(4 Ω/km) |
|
|
