UT Series of Micro-Coax

UT Series of Micro-Coax

UT Series of Micro-Coax

Center Conductor

Material

SPCW ( : SCCS )

SPCW ( : SCCS )

SPCW ( : SCCS )

SPC

SPC

SPC

Structure

Solid

Solid

Solid

Diameter

0.29 mm

0.011 inch

0.51 mm

0.0201 inch

0.92 mm

0.036 inch

1.63 mm

Dielectric

Solid PTFE

0.94 mm

0.037 inch

1.68 mm

0.066 inch

2.98 mm

0.117 inch

5.31 mm

Outer Conductor

TC

Tin Plated Copper Tube

1.19 mm

0.047 inch

2.20 mm

0.086 inch

3.58 mm

0.141 inch

6.35 mm

TA

Tin Plated Aluminum Tube

1.19 mm

0.047 inch

2.18 mm

0.086 inch

3.58 mm

0.141 inch

6.35 mm

BC

Bare Copper Tube

1.19 mm

0.047 inch

2.18 mm

0.086 inch

3.58 mm

0.141 inch

6.35 mm

Weight

 5.7 Kg/Km

1.7 Kg/1000ft

20.2 Kg/Km

6.2 Kg/1000ft

46.7 Kg/Km

14.2 Kg/1000ft

147.0 Kg/Km

Temperature Range (℃)

-55 ~ +125℃

-55 ~ +125℃

-55 ~ +125℃

-55 ~ +125℃

Minimum Bend Radius

6.4 mm

0.25 inch

10.9 mm

0.43 inch

19.1 mm

0.75 inch

19.1 mm

Impedance (Ohms)

50 Ω

50 Ω

50 Ω

Capacitance (pF/ft.)

96.5 pF/M

29.4 pF/ft

96.5 pF/M

29.4 pF/ft

96.5 pF/M

29.4 pF/ft

96.5 pF/M

Velocity of propagation ( % )

70 %

70 %

70 %
